DeviceNet™ Commissioning 5-11
193-DNCT Product Overview The 193-DNCT product is a handheld device that can be used to
commission, configure, program, and monitor other devices on a
DeviceNet™ network. In addition, the 193-DNCT can be used to
upload, store, and later download complete device configurations for
DeviceNet™ devices via the network. The 193-DNCT also has the
capability to present DeviceNet™ physical layer diagnostics and
network bandwidth statistics to the user.
User Manual
For additional information regarding the 193-DNCT, refer to the User
Manual, 193-UM009*.
Bill of Material
The 193-DNCT product package includes the following items:
Accessories
Item Description Quantity
193-DNCT DeviceNet™ Configuration Terminal 1
193-CB1 1 m DNCT Cable with color-coded bare leads 1
193-QR002_-EN-P DeviceNet™ Configuration Terminal Quick Reference 1
Description Catalog No.
1 m DNCT Cable with color-coded bare lead 193-CB1
1 m DNCT Cable with microconnector (male) 193-CM1
Door mount bezel kit 193-DNCT-BZ1
Mini-Mini-Micro Tee for connection to ArmorStart 1485P-P1R5-MN5R1
5-pin connector 1787-PLUG10R
The Bulletin 193 DeviceNet™ Configuration
Terminal should only be used on a DeviceNet™
network.
