Appendix G
Renewal Parts
Figure G.1 Bulletin 280G/281G Control Module Renewal Part Catalog
Structure
Control Module Renewal Part Product Selection
Table G.1 Full Voltage Starters — IP67/NEMA Type 4, Up to 460V AC
Table G.2 Reversing Starters — IP67/NEMA Type 4, Up to 460V AC
Bulletin Number
280 Full Voltage Starter
281 Reversing Starter
Communications
D DeviceNet™
G with six inputs
Enclosure Type
F Type 4 (IP67)
120V AC
12D
23D
Control Module
N Control Module Only
Motor Connection
RG Round
Overload Selection
Current Range
B 0.5…2.5 A
C 1.1…5.5 A
D 3.2…16 A
280 G – F 12D – N B – RG
Contactor Size/Control Voltage
Current Rating
(A)
kW Hp
Cat. No.
400V AC
50 Hz
460V AC
60 Hz
120V AC
0.5…2.5 0.75 1
280G-F12D-NB-RG
1.1…5.5 2.2 3
280G-F12D-NC-RG
3.2…16 7.5 10
280G-F23D-ND-RG
Current Rating
(A)
kW Hp
Cat. No.
400V AC
50 Hz
460V AC
60 Hz
120V AC
0.5…2.5 0.75 1
281G-F12D-NB-RG
1.1…5.5 2.2 3
281G-F12D-NC-RG
3.2…16 7.5 10
281G-F23D-ND-RG
