B-18 Bulletin 280G/281G CIP Information
Parameter Object — CLASS CODE
0x000F
The following class attributes are supported for the Parameter Object:
Table B.42 Parameter Object Class Attributes
The number of instances of the parameter object will depend upon the
type of Distributed Motor Controller. There is a standard set of
instances reserved (1-99) for all starters. These instances are followed
by a unique set of instances for each starter type (Across the Line,
Soft start, or Inverter type).
The following instance attributes are implemented for all parameter
attributes:
Table B.43 Parameter Object Instance Attributes
Attribute ID Access Rule Name Data Type
1 Get Revision UINT
2 Get Max Instance UINT
8 Get Parameter Class Descriptor WORD
9 Get Configuration Assembly Instance UINT
Attribute ID Access Rule Name Data Type
1 Get/Set Value Specified in Descriptor
2 Get Link Path Size USINT
3 Get Link Path
Array of:
BYTE
EPATH
4 Get Descriptor WORD
5 Get Data Type EPATH
6 Get Data Size USINT
7 Get Parameter Name String SHORT_STRING
8 Get Units String SHORT_STRING
9 Get Help String SHORT_STRING
10 Get Minimum Value Specified in Descriptor
11 Get Maximum Value Specified in Descriptor
12 Get Default Value Specified in Descriptor
13 Get Scaling Multiplier UINT
14 Get Scaling Divisor UINT
15 Get Scaling Base UINT
16 Get Scaling Offset INT
17 Get Multiplier Link UINT
18 Get Divisor Link UINT
19 Get Base Link UINT
20 Get Offset Link UINT
21 Get Decimal Precision USINT
