C-28 Bulletin 284G CIP Information
Control Supervisor Object —
CLASS CODE 0x0029
No class attributes will be supported. A single instance (instance 1) of
the Control Supervisor Object will be supported
Table C.59 Instance 1 — Control Supervisor Object.
Attribute ID Access Rule Name Data Type Value
3 Get/Set Run FWD BOOL These Run outputs also map to DOP
instances 1 and 2.
4 Get/Set Run REV BOOL
7 Get Running FWD BOOL
8 Get Running REV BOOL
9 Get Ready BOOL
10 Get Tripped BOOL
12 Get/Set Fault Reset BOOL 0->1 = Trip Reset
100 Get/Set Keypad Mode BOOL 0=Maintained; 1=Momentary
101 Get/Set Keypad Disable BOOL 0=Not Disabled; 1=Disabled
115 Get
Warning Status
WORD
Bits 0-1 = reserved
Bit 2 = reserved
Bit 3 = reserved
Bit 4 = reserved
Bit 5 = CP Warning
Bit 6 = IO Warning
Bit 7 = reserved
Bit 8 = reserved
Bit 9 = DN Warning
Bits 10-12 = reserved
Bit 13 = HW Warning
Bits 14-15 = reserved
124 Get/Set Trip Enable WORD Bit enumerated trip enable word
130 Get/Set Trip Reset Mode BOOL 0=manual; 1=auto
131 Get/Set Trip Reset Level USINT 0 – 100%; default = 75
150 Get/Set High Speed Ena BOOL 0 = Disable; 1 = Enable
151 Get
Base Enclosure
WORD
Bit 0 = IP67
Bit 1 = NEMA 4x
Bits 2-15 reserved
152 Get
Base Options
WORD
Bit 0 = Output Fuse
Bit 1 = Safety Monitor
Bit 2 = CP Fuse Detect
Bits 3-7 = Reserved
Bit 8 = 10A Base
Bit 9 = 25A Base
Bit 10-15 = Reserved
153 Get
Wiring Options
WORD
Bit 0 = Conduit
Bit 1 = Round Media
Bits 2-15 = Reserved
154 Get
Starter Enclosure
WORD
Bit 0 = IP67
Bit 1 = NEMA 4x
Bits 2-15 reserved
156 Get Last PR Trip UINT
157 Get
DB Status
WORD
Bit 0 = DB Faulted
Bit 1 = DB Overtemp Warning
Bit 2= DB On
Bit 3= DB Flt Reset Inhibit
Bits 4-15 reserved
158 Get
DB Fault
WORD
Bit 0 = DB Overtemp
Bit 1 = DB OverCurrent
Bit 2 = DB UnderCurrent
Bit 3 = DBShorted Switch
Bit 4 = DBOpen
Bit 5 = Reserved
Bit 6 = DBBus Voltage Link Open
Bit 7= Reserved
Bit 8= DB Comms
Bits 9-15 = reserved
