B-14 Bulletin 280G/281G CIP Information
The following services are implemented for the Connection Object:
Table B.35 Connection Objects Common Services
Discrete Input Point Object —
CLASS CODE 0x0008
The following class attributes are supported for the Discrete Input
Point Object:
Table B.36 Discrete Input Point Object Class Attributes
Four instances of the Discrete Input Point Object are supported. All
instances contain the following attributes:
Table B.37 Discrete Input Point Object Instance Attributes
The following common services are implemented for the Discrete
Input Point Object:
Table B.38 Discrete Input Point Object Instance Common Services
Service
Code
Implemented for:
Service
Name
Class Instance
0x05 No Yes Reset
0x0E No Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT 2
2 Get Max Instance UINT 6
Attribute ID Access Rule Name Data Type Value
3 Get Value BOOL 0=OFF, 1=ON
115 Get/Set Force Enable BOOL 0=Disable, 1=Enabl;e
116 Get/Set Force Value BOOL 0=OFF, 1=ON
Service
Code
Implemented for:
Service Name
Class Instance
0x0E Yes Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
