Bulletin 284G CIP Information C-25
The following common services are implemented for the Parameter
Object
Table C.50 Parameter Object Common Services:
Parameter Group Object — CLASS
CODE 0x0010
The following class attributes are supported for the Parameter Object
Table C.51 Parameter Group Object Class Attributes:
All Bulletin 284G Motor Starters have the following instances of the
parameter group object:
• Instance 1 = DeviceLogix Parameters
• Instance 2 = DeviceNet Parameters
• Instance 3 = Starter Protection Parameters
• Instance 4 = User I/O Parameters
• Instance 5 = Miscellaneous
• Instance 6 = Drive DNet
• Instance 7 = ZIP Parameters
• Instance 8 = Basic Display
• Instance 9 = Basic Program
• Instance 10 = Advanced Program
Service
Code
Implemented for
Service
Name
Class Instance
0x0E Yes Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
0x01 No Yes Get_Attributes_All
Attribute ID Access Rule Name Data Type
1 Get Revision UINT
2 Get Max Instance UINT
