Page #229 background imageLoading...
Page #229 background image
Bulletin 280G/281G CIP Information B-5
Assembly Object — CLASS CODE
0x0004
The following class attributes are supported for the Assembly Object:
Table B.12 Assembly Object Class Attributes
All of the various instances of the assembly object will support
attribute 3. The following table summarizes the various instances that
are supported:
Table B.13 DeviceNet Assembly Object Instance Attributes
Custom Parameter Based
“Word-wise” I/O Assemblies
Table B.14 Custom Parameter Based “Word-Wise” (Produced) Assembly
Instance 120
Attribute ID Access Rule Name Data Type Value
2 Get Max Instance UINT 190
Attribute ID Type Description
3 Consumed Required ODVA Consumed Instance
52 Produced Required ODVA Produced Instance
120 Produced Custom Parameter Based Word Wise Assembly
160 Consumed Default Consumed Instance for DOL
161 Produced Default Produced Instance for DOL
162 Consumed Standard Consumed Instance for DOL with Network Inputs
163 Produced Standard Produced Instance for DOL with Network Outputs
181 Produced User Inputs
182 Consumed Consumed Network Bits (a.k.a Network Inputs)
183 Produced Produced Network Bits (a.k.a. Network Outputs)
184 Produced Trip Status Bits
185 Produced Starter Status Bits
186 Produced DeviceNet Status Bits
187 Consumed Starter Control Bits
189 Produced Warning Status Bits
190 Produced 1779-ZCIO Bits
Instance 120
Word Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0
0
Value of the parameter pointed to by “Prod Assy Word 0” Param (low byte)
1
Value of the parameter pointed to by “Prod Assy Word 0” Param (high byte)
1
2
Value of the parameter pointed to by “Prod Assy Word 1” Param (low byte)
3
Value of the parameter pointed to by “Prod Assy Word 1” Param (high byte)
2
4
Value of the parameter pointed to by “Prod Assy Word 2” Param (low byte)
5
Value of the parameter pointed to by “Prod Assy Word 2” Param (high byte)
3
6
Value of the parameter pointed to by “Prod Assy Word 3” Param (low byte)
7
Value of the parameter pointed to by “Prod Assy Word 3” Param (high byte)
