Bulletin 280G/281G CIP Information B-3
Identity Object — CLASS CODE
0x0001
The following class attributes are supported for the Identity Object:
Table B.6 Identity Object Class Attributes
Identity Objects A single instance of the Identity Object is supported. The following
instance attributes are supported.
Table B.7 Identity Object Instance Attributes
The following common services are implemented for the Identity
Object:
Table B.8 Identity Object Common Services
Message Router — CLASS CODE
0x0002
No class or instance attributes are supported. The message router
object exists only to rout explicit messages to other objects.
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT 1
Attribute ID Access Rule Name Data Type Value
1 Get Vendor UINT 1
2 Get Device Type UINT 22
3 Get Product Code UINT See Table B.1 and Table B.3
4Get
Revision
Major Revision
Minor Revision
Structure of:
USINT
USINT
Indicates Software Firmware Revision Number
5Get Status WORD
Bit 0 — 0=not owned; 1=owned by master
Bit 2 — 0=Factory Defaulted; 1=Configured
Bit 8 — Minor Recoverable fault
Bit 9 — Minor Unrecoverable fault
Bit 10 — Major Recoverable fault
Bit 11 — Major Unrecoverable fault
6 Get Serial Number UDINT Unique Number for Each Device
7Get
Product Name
String Length
ASCII String
Structure of:
USINT
STRING
Product code specific
See Table B.1 and Table B.3
8 Get State USINT Returns the value “3=Operational”
9 Get Configuration Consistency Value UINT
Unique value depending on output of the parameter
checksum algorithm.
10 Get/Set Heartbeat Interval USINT In seconds. Default = 0
Service
Code
Implemented for:
Service
Name
Class Instance
0x0E Yes Yes Get_Attribute_Single
0x05 No Yes Reset
0x10 No Yes Set_Attribute_Single
