B-22 Bulletin 280G/281G CIP Information
Control Supervisor Object -CLASS
CODE 0x0029
No class attributes are supported.
The following instance attributes are supported:
A single instance (instance 1) of the Control Supervisor Object will
be supported.
Table B.52 Control Supervisor Instance Attributes
Attribute ID Access Rule Name Data Type Value
3 Get/Set Run 1 BOOL
These Run outputs also map to DOP instances 1
and 2.
*4 Get/Set Run 2 BOOL
7 Get Running 1 BOOL Status of RUN FWD contact
*8 Get Running 2 BOOL Status of RUN REV contact
9 Get Ready BOOL Device not faulted
10 Get Tripped BOOL Device faulted
12 Get/Set Fault Reset BOOL 0->1 = Trip Reset
100 Get/Set Keypad Mode BOOL 0=Maintained; 1=Momentary
101 Get/Set Keypad Disable BOOL 0=Not Disabled; 1=Disabled
115 Get Warning Status WORD
Bits 0-4 = reserved
Bit 5 = CP Warning
Bit 6 = IO Warning
Bit 7 = reserved
Bit 8 = reserved
Bit 9 = DN Warning
Bits 10-12 = reserved
Bit 13 = HW Warning
Bits 14-15 = reserved
124 Get/Set Trip Enable WORD Bit enumerated trip enable word
130 Get/Set Trip Reset Mode BOOL 0=manual; 1=auto
131 Get/Set Trip Reset Level USINT 0 – 100%; default = 75
151 Get Base Enclosure WORD
Bit 0 = IP67
Bits 1-15 reserved
152 Get Base Options WORD
Bit 0 = reserved
Bit 1 = reserved
Bit 2 = CP Fuse Detect
Bits 3-7 = reserved
Bit 8 = 10A Base
Bit 9 = 25A Base
Bit 10-15 = reserved
153 Get Wiring Options WORD
Bit 0 = reserved
Bit 1 = reserved
Bit 2= 28xG Gland
Bits 3-15 = reserved
154 Get Starter Enclosure WORD
Bit 0 = IP67
Bits 1-15 reserved
155 Get Starter Options WORD
Bit 0 = Full Keypad
Bit 1 = Safety Monitor
Bits 2-15 reserved
156 Get Last Pr Trip UINT See Parameter 61
