Bulletin 280G/281G CIP Information B-13
Instances 5 and 6 are available group 3 explicit message connections
that are allocated through the UCMM. The following attributes are
supported:
Table B.33 Connection Object Instance 5-6 Attributes
Instances 8-11 are ZIP Consumers. The following instance attributes
will be supported:
Table B.34 Connection Object Instances 8-11 Attributes
Attribute ID Access Rule Name Data Type Value
1 Get State USINT
0=nonexistant
1=configuring
3=established
4=timed out
2 Get Instance Type USINT
0=Explicit
Message
3 Get Transport Class Trigger USINT 0x83 — Server, Transport Class 3
4 Get Produced Connection ID UINT Depends on message group and Message ID
5 Get Consumed Connection ID UINT Depends on message group and Message ID
6 Get Initial Comm Characteristics USINT 0x33 (Group 3)
7 Get Produced Connection Size UINT 0
8 Get Consumed Connection Size UINT 0XFFFF
9 Get/Set Expected Packet Rate UINT in ms
12 Get Watchdog Action USINT
01 = auto delete
03 = deferred delete
13 Get Produced Connection Path Length UINT 0
14 Get Produced Connection Path Empty
15 Get Consumed Connection Path Length UINT 0
16 Get Consumed Connection Path Empty
Attribute ID Access Rule Name Data Type Value
1 Get State USINT
0=nonexistant
1=configuring
3=established
2 Get Instance Type USINT 1=I/O Connection
3 Get Transport Class Trigger USINT 0x20 (COS, unacknowledged)
4 Get Produced Connection ID UINT FFFF (not producing data)
5 Get Consumed Connection ID UINT
01101xxxxxx
xxxxxx=node address
6 Get Initial Comm Characteristics USINT 0xF0 (unacknowledged)
7 Get Produced Connection Size UINT 0
8 Get Consumed Connection Size UINT 8
9 Get/Set Expected Packet Rate UINT in milliseconds
12 Get Watchdog Action USINT 2=auto reset
13 Get Produced Connection Path Length UINT 0
14 Get Produced Connection Path 0
15 Get Consumed Connection Path Length UINT 8
16 Get Consumed Connection Path 21 0E 03 25 01 00 30 02
