Roland V-Drums TD-20X User Manual

109
Chapter 9. Settings for the Entire TD-20X [SETUP]
• [F4 (OTHER)] screen
4.
Use the [VALUE], the [-] [+], or [CURSOR (up/down)]
buttons to select the output destination.
5.
Press the [EXIT] button to return to the “SETUP”
screen.
“Block Diagram” (p. 144)
The MASTER OUT L/R jacks and the DIRECT OUT 1–8
jacks are unbalanced.
Default settings
As the chart below illustrates, the PHONES jack and the
MASTER OUT L/ R jacks will output all sounds. Individual
sounds are assigned to DIRECT OUTS 1-8 for individual sound
control with a PA system.
Sending the same audio for monitoring and
PA
With these settings, the same sound will be output from the
PHONES jack, the MASTER OUT L/R jacks, and the DIRECT OUT
7/8 jacks.
The sound being monitored by the performer will be the
same as the sound sent to the PA system.
Sending Ambience and/or MFX separately
This chart shows how you can use the MASTER OUT L/R jacks.
to output the Ambience and/or MFX (
multi effects
). This allows
the PA engineer to balance the effects with the individual
sounds.
Indication
Description
AMB
Ambience (p. 60)
MFX Multi-effects (p. 62)
BACK The pattern’s backing parts (p. 72)
PERC The pattern’s percussion part (p. 73)
CLICK Metronome click (p. 81)
MIXIN The sound being input to the MIX IN jack
Example Settings
Jack
Output
Example
destination
PHONES
All
Monitor
headphones
MASTER All
Drum monitor
DIRECT OUT 1 KICK
PA (external
mixer)
DIRECT OUT 2 SNARE
DIRECT OUT 3 HI-HAT
DIRECT OUT 4 RIDE, EDGE
DIRECT OUT 5/6 TOM1–4 (Stereo)
DIRECT OUT 7/8
CRASH1, 2,
AUX1–4 (Stereo)
Jack
Output
Example
destination
PHONES
All
Monitor
headphones
MASTER All
Drum monitor
DIRECT OUT 1 — —
DIRECT OUT 2 —
—
DIRECT OUT 3 —
—
DIRECT OUT 4 —
—
DIRECT OUT 5/6 —
—
DIRECT OUT 7/8 All
PA (external
mixer)
Jack
Output
Example
destination
PHONES All
Monitor
headphones,
drum monitor
MASTER
Ambience,
MFX
PA (external
mixer)
DIRECT OUT 1 KICK
DIRECT OUT 2 SNARE
DIRECT OUT 3 HI-HAT
DIRECT OUT 4 RIDE, EDGE
DIRECT OUT 5/6 TOM1–4 (Stereo)
DIRECT OUT 7/8
CRASH1, 2,
AUX1–4 (Stereo
TD-20X_e.book 109 ページ ２００９年６月８日 月曜日 午後３時５０分

Roland V-Drums TD-20X Specifications

General

MIDI	Yes
USB	Yes
Metronome	Yes
Display	LCD
Polyphony	64 voices
Sequencer	Yes
Headphone Output	Yes
Power Supply	AC Adapter
Effects	Reverb, Delay
Type	Electronic drum module
Kits	100 (50 preset, 50 user)
Connectors	MIDI In/Out, Audio Outputs
Trigger Inputs	12 inputs
