Specifications and Reference Data
133
Specifications and Reference Data
September 2017
Reference Manual
00809-0100-4803, Rev GA
Process-wetted parts
Process isolating diaphragms
 316L SST (UNS S31603)
 Alloy C-276 (UNS N10276)
 Alloy 400 (UNS N04400)
 Tantalum (UNS R05440)
 Gold-plated Alloy 400
 Gold-plated 316L SST
Drain/vent valves
316 SST, Alloy C-276, or Alloy 400/K-500 material
(Drain vent seat: alloy 400, drain vent stem: Alloy K-500)
Process flanges and adapters
 Plated carbon steel
 SST: CF-8M (Cast 316 SST) per ASTM A743
 Cast C-276: CW-12MW per ASTM A494
 Cast Alloy 400: M-30C per ASTM A494
Wetted O-rings
Glass-filled PTFE
(Graphite-filled PTFE with isolating diaphragm code 6)
Non-wetted parts
Electronics housing
 Low-copper aluminum alloy or SST: CF-3M (Cast 316L SST)
or CF-8M (Cast 316 SST)
 NEMA
®
4X, IP 66, IP 68 (66 ft. [20 m] for 168 hours)
Coplanar sensor module housing
SST: CF-3M (Cast 316L SST)
Bolts
 Plated carbon steel per ASTM A449, Type 1
 Austenitic 316 SST per ASTM F593
 ASTM A453, Class D, Grade 660 SST
 ASTM A193, Grade B7M alloy steel
 ASTM A193, Class 2, Grade B8M SST
 Alloy K-500
Sensor module fill fluid
Silicone or inert halocarbon
Paint
Polyurethane
Cover O-rings
Buna-N
Shipping weights for Rosemount 3051S
MultiVariable Transmitter (3051SMV)
Rosemount 3051SMV with Plantweb
™
housing: 6.7 lb
(3,1 kg)
Table A-5. Transmitter Option Weights
Option
code
Option
Add
lb (kg)
1J, 1K, 1L SST Plantweb housing 3.5 (1,6)
1A, 1B, 1C Aluminum Plantweb housing 1.1 (0,5)
M5
(1)
1. Includes LCD display and display cover.
LCD display for Aluminum Plantweb
housing
0.8 (0,4)
LCD display for SST Plantweb housing 1.6 (0,7)
B4
SST mounting bracket for coplanar
flange
1.2 (0,5)
B1, B2, B3 Mounting bracket for traditional flange 1.7 (0,8)
B7, B8, B9
Mounting bracket for traditional flange
with SST bolts
1.7 (0,8)
BA, BC SST bracket for traditional flange 1.6 (0,7)
B4 SST mounting bracket for In-Line 1.3 (0,6)
F12, F22
(2)
2. Includes mounting bolts.
SST traditional flange with SST drain
vents
3.2 (1,5)
F13, F23
(2)
Cast C-276 traditional flange with alloy
C-276 drain vents
3.6 (1,6)
E12, E22
(2)
SST coplanar flange with SST drain
vents
1.9 (0,9)
F14, F24
(2)
Cast alloy 400 traditional flange with
alloy 400/K-500 drain vents
3.6 (1,6)
F15, F25
(2)
SST traditional flange with alloy C-276
drain vents
3.2 (1,5)
G21 Level flange—3-in., 150 12.6 (5,7)
G22 Level flange—3-in., 300 15.9 (7,2)
G11 Level flange—2-in., 150 6.8 (3,1)
G12 Level flange—2-in., 300 8.2 (3,7)
G31 DIN Level flange, SST, DN 50, PN 40 7.8 (3,5)
G41 DIN Level flange, SST, DN 80, PN 40 13.0 (5,9)
