Figure A-3. Plantweb Housing with Coplanar SuperModule Platform and Rosemount 305 Traditional Integral
Manifold
A.
1
/2–14 NPT on mounting adapters
B. Drain vent valve
C.
1
/4–18 NPT
Dimensions are in inches (millimeters).
Figure A-4. Plantweb Housing with Coplanar SuperModule Platform and Traditional Flange
Dimensions are in inches (millimeters).
C
1.63
(41)
2.13
(54)
6.80 (173)
max open
9.72 (247)
max open
2.70
(69)
1.10
(28)
3.40
(86)
1.16
(29)
3.56
(90)
max open
A
B
1.63
(41)
2.13
(54)
9.30
(236)
3.40
(86)
1.10
(28)
