Figure A-5. Traditional Flange Mounting Configurations
Dimensions are in inches (millimeters).
Pipe mount Rosemount 305 Integral manifold Panel mount
8.10
(206)
3.56 (90)
max open
1.10
(28)
3.42
(87)
2.62
(67)
0.93
(24)
13.03
(331)
4.85
(123)
3.56 (90)
max open
1.10
(28)
3.40
(86)
1.94
(49)
7.70
(196)
5.32
(135)
10.71
(272)
2.62
(67)
7.70
(196)
