26
Reference Manual
00809-0100-4803, Rev GA
Configuration
September 2017
Configuration
Under the Energy Rate heading (fully compensated mass and energy flow feature board only), the Units
and Damping for the Energy Rate may be edited.
Note
Energy rate calculations are only available for steam and natural gas.
The energy rate calculation within the device uses undamped process variables. Energy rate damping is
set independently of flow rate damping or measured process variables.
Under the Differential Pressure heading, the Units and Damping for the Differential Pressure may be
edited.
Under the Static Pressure heading, the Units for both absolute and gage pressure and static pressure
Damping may be edited.
Note
Both absolute and gage pressure are available as variables. The type of transmitter ordered will
determine which variable is measured and which is calculated based on the user defined atmospheric
pressure. For more information on configuring the atmospheric pressure, see “Static pressure” on
page 53. Since only one of the static pressures is actually being measured, there is a single damping
setting for both variables which may be edited under the Static Pressure heading.
Under the Process Temperature heading, the Units and Damping for the Process Temperature may be
edited.
Under the Module Temperature heading, the Units for the sensor module temperature may be set. The
sensor module temperature measurement is taken within the module, near the differential pressure
and/or static pressure sensors and can be used to control heat tracing or diagnose device overheating.
Under the Analog Output heading, the primary variable can be selected from the drop down menu and
the upper and lower range values (4 and 20 mA points) for the primary variable may be edited.
Under the Totalizer heading (fully compensated mass and energy flow feature board only), the Totalizer
can be configured by selecting the Configure Totalizer button. This button allows the user to select
the variable to be totalized. The Totalizer Units may also be edited under this heading.
