46
Reference Manual
00809-0100-4803, Rev GA
Configuration
September 2017
Configuration
Energy conversion example
To find the Base per Custom relationship for a custom unit of thousands of BTU per hour (kBtuh) and a
base unit of BTU per hour (Btu/h), input the following:
Custom Unit = kBtuh
Base Unit = Btu/h
Because:
1 kBtu (Thousands of BTU) = 1000 Btu
Then:
1 kBtuh = ⫻ = 1000 Btu/h
1 kBtuh = 1000 Btu/h
Therefore:
Base per Custom = = = 1000
Figure 2-31. Energy Rate Custom Units - Energy Conversion Example
1kBtu⋅
1h⋅
--------------------
1000 Btu⋅
1h⋅
---------------------------
Number of Base Units
1xCustomxUnit
----------------------------------------------------------------------
1000 Btu h⁄⋅
1kBtuh⋅
----------------------------------
