Reference Manual
00809-0100-4803, Rev GA
Configuration
September 2017
Configuration
Differential Pressure Reading and Status 1, 4, 2, 1, 1
Differential Pressure Sensor Trim Options 1, 2, 4, 3
⻫
Differential Pressure Zero Trim 1, 2, 4, 3, 1
⻫
Differential Pressure Units 1, 3, 3, 1
Equipped Sensors 1, 4, 4, 3
Field Device Information 1, 4, 4, 1
Gage Pressure Reading and Status 1, 4, 2, 1, 3
Gage Pressure Sensor Limits 1, 4, 1, 2, 9
⻫
Gage Pressure Units 1, 3, 3, 3
LCD Display Configuration 1, 3, 8
Loop Test 1, 2, 2
Module Temperature Reading and Status 1, 4, 2, 1, 5
Module Temperature Units 1, 3, 3, 5
Poll Address 1, 4, 3, 3, 1
Process Temperature Reading and Status 1, 4, 2, 1, 4
Process Temperature Sensor Trim Options 1, 2, 4, 5
⻫
Process Temperature Unit 1, 3, 3, 4
⻫
Ranging the Analog Output 1, 2, 4, 1
Recall Factory Trim Settings 1, 2, 4, 2, 3
Sensor Information 1, 4, 4, 2
⻫
Static Pressure Sensor Lower Trim (AP Sensor) 1, 2, 4, 4, 2
Static Pressure Sensor Trim Options 1, 2, 4, 4
⻫
Static Pressure Sensor Zero Trim (GP Sensor) 1, 2, 4, 4, 1
⻫
Status 1, 2, 1
⻫
Tag 1, 3, 1
⻫
Transfer Function 1, 3, 6
Variable Mapping 1, 4, 3, 4
Write Protect 1, 3, 5, 4
Table 2-14. Fast Keys for Direct Process Variable Measurement
Function Fast Key sequence
