5- Information / Configuration
Page 5-20 F@ST 4310 Reference Manual
Sagemcom Broadband SAS document. Reproduction and disclosure prohibited
Select DSL Link
Type
Select the type of network protocol from the scroll down list:
• EoA: Ethernet over ATM
• PPPoA: PPP over ATM
• IPoA: IP over ATM
Note: EoA is for PPPoE and IPoE.
EoA
Select Connection
Mode
Select the connection mode:
• Default Mode - Single service over one connection
• VLAN MUX Mode - Multiple Vlan service over one connection
For more details, a summary table is presented below for each
type of protocol.
Encapsulation
mode
Select the encapsulation mode for the selected DSL link type.
For more details, a summary table is presented below for each
type of protocol.
LLC/SNAP
-
BRIDGING
Service Category
Select the type of service adapter to the traffic from the scroll
down list:
• UBR without PCR: Unspecified Bit Rate
• UBR with PCR: Unspecified Bit Rate
• CBR: Constant Bit Rate
• Non Realtime VBR: Variable Bit Rate
• Realtime VBR: Variable Bit Rate
UBR
without
PCR
Select IP QoS
Scheduler
Algorithm
• Strict Priority
-Precedence of the lowest queue:
• Weighted Fair Queuing
-Weight Value of the default queue: [1-63]
-MPAAL Group of Precedence:
8 (lowest)
1
8
Peak Cell Rate
b
Enter a maximum number of cells transmitted per second,
between 1 and 2491.
-
Sustainable Cell
Rate
c
Enter an average number of cells transmitted per second.
Note: This number must be lower than the Peak Cell
Rate (PCR).
-
Maximum Burst
Size
c.
Enter the maximum number of cells emitted in burst (value
between 1 and 1000 000).
-
a. This value is delivered to you by your Internet Service Provider (ISP).
b. This field only appears when the "UBR with PCR", "CBR", "Non Realtime VBR" or "Realtime VBR" type
of service is selected.
c. These fields only appear when the "Non Realtime VBR" or "Realtime VBR" type of service is selected.
Field Action
Default
value
