transmission
gearbox
3
31
Fig. 58 - Lay a bead of sealant (Pianermetic 510) on the top
surface of the transmission housing where the lift housing is
to sit.
Fig. 60 - Settle the lift housing on top of the transmission
housing.
Fig. 62 - Locate the thrust bearing control mechanism in the
intermediate housing, complete with operating lever.
Fig. 59 - Using a hoist, position the hydraulic lift over the
transmission housing.
Fig. 61 - Proceed to tighten the bolts securing the lift housing
to the transmission housing, torquing to 8,6 Kg.
Fig. 63 - Using a hoist, position the engine in contact with the
intermediate housing.
162
