Power-lift distributor valve spring setting specifications
Oil flow control valve spring
no. of springs used no. 1
wire diameter mm 1.4
external diameter mm 7.8
released spring mm 54
loaded spring (N 40.4) - kg 4.115 mm 47.5
(N 66) - kg 6.727 mm 43.4
Pilot valve spring
no. of springs used no. 1
wire diameter mm 0.9
external diameter mm 7.8
released spring mm 25.5
loaded spring (N 21) - kg 2.133 mm 15.2
(N 28.5) - kg 2.899 mm 11.5
Hydraulic distributor spring
no. of springs used no. 1
wire diameter mm 1.2
external diameter mm 10.4
released spring mm 110
loaded spring (N 43) - kg 4.4 mm 65
(N 39) - kg 4 mm 60
Nonreturn valve spring
no. of springs used no. 2
wire diameter mm 1.1
external diameter mm 8.8
released spring mm 25
loaded spring (N 29) - kg 2.96 mm 17
(N 43) - kg 4.43 mm 13
Valvematic spring
no. of springs used no. 1
wire diameter mm 1.2
external diameter mm 9,5
released spring mm 57,3
loaded spring (N 41,3) - kg 4,2 mm 35
(N 54,3) - kg 5,5 mm 25,8
59
5
vehicle
rear hydraulic power-lift
280
