Fig. 1 - Extendible front axle.
Specifications
drive axles - axles
2-W.D. extendible axle
toe-in mm 2 to 6
wheel caster angle 0°
axle swinging angle 12°
tyre inflating pressure bar 2.4
lubricating grease type AKROS GREASE T2
steering angle 70°
2-W.D. front extendible axle
General information
The wide sideways front axle swinging obtained through excellent anchoring, not only makes it possible to operate the
tractor nimbly on steep slopes but also permits the axle to be easily removed from tractor when any repair is to be
performed. End play check is the only operation required on axle reassembly.
The telescopic-type axle is extremely rugged and enables the tread to be adapted to any work requirements without
removing the hydrostatic steering cylinder.
