About the on-board computer
When power is supplied to the system, pressing the "INFO/PAR" key (9, Fig 1) will bring up a video page showing
essential information about the type of program installed.
Verifying correct operation of the Performance Monitor
Press "INFO/PAR" and execute the following procedure:
If the computer has been powered up for less than 30 seconds, a “please wait” message is displayed; thereafter, the
video page illustrated above will appear.
If the page in question does not appear, conversely, this means that there is a problem in the interface with the lift
system, and the connections between the two units must therefore be checked over.
PERFORMANCE MONITOR RETROFIT PROCEDURE
Parts required:
PERFORMANCE MONITOR p/n 009.7680.0
BLANKING PLUG p/n 010.0839.4
EPROM for machines equipped with SBA System p/n 010.2090.2 sw 1.00
EPROM for machines not equipped with SBA System p/n 010.2090.0 sw 1.00
PLASTIC CLIP
To ensure correct installation of the equipment, observe the following directions with due care and attention:
1 - Remove the electronic lift control unit (1, fig 3 - page 246) from its slot. Remember when carrying out this step
that the unit is retained by means of a snap fit.
2 - Disconnect the unit from the electrical system of the machine by rotating the black multiway connector.
3 - Unfasten the 6 securing screws of the rear cover and locate the printed circuit board to enable replacement of
the EPROM with the new type.
This involves removing the plastic clip by which the EPROM is secured to the base.
Caution: Before installing the new EPROM, check that it is marked with the letters SBA, in the event that the machine
is equipped with SBA system; similarly, if the vehicle is not equipped with the system, the EPROM should not be
marked SBA.
— Position the new EPROM, with the notch on one of the two shorter sides facing toward the microprocessor (the
flat square component alongside). Care must be taken when positioning, to ensure that all contacts are aligned
with the respective sockets.
— Refit the cover and reconnect the unit to the original wiring harness.
— Looking through the slot which houses the control unit, locate the white multiway connector coupled to the wiring
of the lift system only (see electrical diagram of sheet 9 in electrical systems chapter).
— Remove the blanking plug from the Performance Monitor bay, withdraw the connector identified previously and
plug into the Performance Monitor; now insert the Performance Monitor into the bay, applying pressure sufficient
to snap the case into position.
— Insert the lift control unit into its slot.
— Insert the blanking plug (supplied with the kit) to the right of the Performance Monitor.
— Proceed with setup operations, following the directions given on page 338.
