ALL ROUND TESTER
The tester is connected to the diagnostics socket on the right hand side of the instrument panel, and allows dialogue
with the control unit of the electronic lift system.
To enable communication, a PASSWORD must first be entered to gain access to the control unit.
The password is installed by the tractor manufacturer during factory testing.
If the diagnostics facility needs to be utilized for any reason, proceed as follows:
— stop the engine and switch off the ignition
— connect the tester to the diagnostics socket
— switch on the panel by pressing and holding key [ A ]
— the tester will prompt "PASSWORD:"
— press keys [ 1 ] [ 2 ] [ 3 ] [ F ]
— press key [ 2 ]
— press keys [ 1 ] [ Ø ] [ Ø ] [ Ø ] [ 1 ] [ 1 ] [ 1 ]
— press key [ E ]
— press key [ E ]
— the tester is now programmed for operation
Should it happen (having enabled the communication line) that the tester fails to establish a connection with the lift
control unit, check the connection between Pin 21 of the connector at the lift control unit and Pin 7 of the diagnostics
socket; if there is no apparent fault with the connection, have the tester checked over by a specialist technician.
The software of the electronic lift control unit is programmed to display a series of video pages by way of the ALL
ROUND TESTER: these are illustrated below.
CONTROL PANEL
POT. LEVEL 101%
POT. SENSIT. 102%
POT. SEED 102%
EV UP BUTTON - R-
EV DW BUTTON - R-
SLIP BUTTON - R-
POS. BUTTON - R-
DRAFT BUTTON - R-
STOP BUTTON - R-
MAX HEIGH BUT - R-
TRANSP. BUTT. - R-
( _ ) SELECTION
REAR LIFT
1 - TEST
2 - CALIBRATIONS
3 - TARE MAX. POS.
4 - LIMITS
5 - MONITOR
6 - ALARMS
7 - TARE STEERING
TESTS
1 - CONTROL PANEL
2 - EXTBTTN/C. UNIT
3 - DYNAMIC TEST
4 - SELF - DIAGNOSIS
5 - SBA
( E ) EXIT
Menu 1.1
Menu 1.
Menu 1.1.1
( E ) EXIT
PRES BOTTON_
S+L+H S.p.A.
ELECTRONIC
LIFT
SOFTWARE VERSION
1.00 ss
HW VERSION 2.0
SERIAL NO. 1194
1- ENGINE ECU
Menu 0
( _ ) SELECTION_
59
5
vehicle
electronic power-lift
234
