Fig. 3 - Monitoring and control unit, and radar.
1 - Electronic control unit and operating controls
2 - SBA System control
3 - Position control sensor
4 - Brake switches (with SBA System)
5 - Radar
6 - Transmission speed sensor
7 - Wiring harness
8 - External lift controls mounted to fenders
9 - Draft control sensor
59
5
vehicle
electronic power-lift
246
