SAME SILVER 100.4 - Page 70

VOLTAGE SPECIFICATIONS UNDER NORMAL OPERATING CONDITIONS
Voltage measurements should be taken with power supplied by the switched on ignition key, whilst resistance
measurement should be performed with battery disconnected.
UNIT
• actuator :
MEASUREMENT
—
resistance
— current
— voltage
2.3± 0.5 ohm
open circuit
0.15÷ 0.3A
1.5÷ 1.7A
1.9÷ 2.4A
0.3÷ 0.8V
3.6÷ 4V
4.5÷ 5.8V
CONDITION
—
between terminals
— between terminals and
earth
— card supplied
— engine idling
— full-load engine running
— card supplied
— engine idling
— full-load engine running
UNIT
• pick-up
MEASUREMENT
—
resistance
— voltage
1000± 200 ohm
open circuit
3V alternated voltage
10V alternated voltage
CONDITION
—
between terminals
— between terminals and
earth
— during engine starting
— engine idling
engine
fuel system
16
1
70
