NexU INSTALLATION MANUAL
12
Yellow wiring represents the customer computer network.
For Samoa cabling red and black wires
are used for power and white, blue and
screen are used for data.
NOTE: Although wiring colors could be used in another way, it is highly
recommended to follow this rule.
3.1.2 WIRELESS INSTALLATION
In this case the UNet is connected to a Wi-Fi Router (Samoa Supply) and it connects (and
transfers information) to a UDat. This UDat powers up and transfers information to the rest
of the elements.
