Rev 3 (XXXX 2019)
NexU INSTALLATION MANUAL
81
7.2 DEVICES
7.2.1 DISPENSE POINT
This screen shows a complete situation of the connected reels. Also in this window you
can change some of the parameters.
First column: There is a little picture of the device.
Second column: The address is shown. It represents the number of the local
parameter.
Third column: It shows the description of the device. This description is the one that
was set in the configuration menu.
Fourth column: It shows the loaded device firmware version.
Fifth column: It shows the product that is delivered (if the device is a delivery one) or
shown (if the device is a display one)
Sixth column: It shows the way the device is connected. It can be either wired or Wi-Fi
linked. A date/time is shown as well. This indicates the last moment in which right
communication was held between the UNet and the device. If date/time is old, it
means that there is something wrong with the communication.
Seventh column: It shows the status of the device. In the above screenshot you can
see that all of them are OK (fully operational).
Eighth column: In this column you can edit some of the device parameters. If you
press the icon , a pop up window appears and you will be able to change some of
the parameters. For UValve / UCount you can change the following parameters
