NexU INSTALLATION MANUAL
41
3.3.13 CABLING FROM UNET TO UDAT / UDAT+
In this case, as both units are powered up by an external source, the only wire that
have to be connected are SHIELD / WHITE / BLUE (Communication)
3.3.14 CABLING FROM UTANK TO UDAT / UDAT+
In this case, as both units are powered up by an external source, the only wire that
have to be connected are SHIELD / WHITE / BLUE (Communication)
3.3.15 CABLING FROM UTANK TO UVALVE / UMETER / UMETER+
In this case, as both units are powered up by an external source, the only wire that
have to be connected are SHIELD / WHITE / BLUE (Communication)
