NexU INSTALLATION MANUAL
44
The EOL resistors have to be set at the ends of the CANBUS installation. In the above
figure, the EOL are set at the UNet and the UDat (blue dot). If the installation is Wi-Fi
based or Hybrid based, the EOL resistors have to be set at the end of each CANBUS.
