Sanyo PLC HF10000L User Manual

54
Settings
Select the background color or image when no input signal
is detected. Press the Point ed buttons to switch between
each option.
Blue ................... Projects a blue background.
User ................... Projects a captured image.
Black .................. Projects a black background.
Allows you to select a lamp mode.
2-Lamps ................ Uses two lamps.
1-Lamp .................. Uses one lamp.
Auto: Automatically and preferentially
uses a lamp with shorter cumulated
lighting time.
Constant mode ..... Automatically switches between
2-Lamps mode and 1-Lamp mode,
or performs digital processings like
modulation of the light from the lamp(s)
to keep the target brightness by
switching the lamp modes.
Target: Allows you to specify the desired
target brightness (up to 1024). Follow
these steps below: 1) Select Target
and press the SELECT button. 2) Set
Target brightness by using the Point ed
buttons and press the SELECT button. 3)
Select Yes in the confirmation dialog box
to activate Constant mode.
Current: Displays current brightness. If
luminance level of lamp does not reach
the target brightness, the parameter is
displayed in red.
This function allows you to change among the lamp
modes: Auto, Normal, Eco 1, and Eco 2
Lamp control
Auto . . . . Brightness according to the input signal.
Normal . . Normal brightness.
Eco 1. . . . Lowers brightness and decrease of fan
speed. Lower brightness reduces the
lamp power consumption and extends
the lamp life.
Eco 2. . . . Lowers brightness and increase of fan
speed. Lower brightness reduces the
lamp power consumption and extends
the lamp life. It is recommended to
use Eco 2 when using the projector
continuously over a long period of time.
The fan noise becomes louder in Eco 2
than in Eco 1. Select the suitable mode
for the used environment.
✔Note
The fan noise becomes louder in Eco 2 than in Eco 1.
Select the suitable mode for the used environment.
✔Note
• In Constant mode, some Setting menu items are not
available.
• You can use the Real Color Manager Pro CD-ROM
(supplied) except in Constant mode.
• In this example, the Target value is specified to 820, but
as it is not absolute luminance, you can specify a value
in the 0 - 1024 range.
Background
Lamp mode
Lamp control

Sanyo PLC HF10000L Specifications

General

Matrix size	1.65 \
Matrix type	3-panel (p-Si TFT active)
Projection distance	- m
Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 120 kHz
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	- \
Projector native resolution	-
Keystone correction, horizontal	30 °
Interface	USB
Power LED	Yes
RS-232 ports	2
Dimensions (WxDxH)	530 x 757 x 268 mm
Focus	Auto
Focal length range	- mm
Noise level	43 dB
Noise level (economic mode)	39 dB
Dot clock scanning frequency	230 MHz
Lamp power	380 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Composite video in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Wi-Fi	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Product color	Gray
Power consumption (standby)	18 W
Power consumption (typical)	955 W
Cables included	AC, RS-232

Weight and Dimensions

Weight	27600 g
