SECTION V
SCHEMATICS AND DIAGRAMS
5.3 Hand Control Messages
Table 5-1 lists all the hand control messages which
could display on the hand control and gives a brief
description of what each message means.
Table 5-1. Hand Control Messages
Page 5-5Printed in U.S.A.
Hand Control Messages Description of Message
WAIT . . . Informs the operator that the microprocessor is "booting up" and checking the status of all switches and
sensors.
NORMAL POSITION Informs the operator that the table top is in the normal configuration.
REVERSE POSITION Informs the operator that the table top is in the reverse configuration.
TO UNLOCK PRESS / ENABLE &
UNLOCK
When the operator presses the unlock button only, this message informs the operator that the ENABLE
button must also be pressed.
HOLD FOR 3 SEC Informs the operator that the ENABLE and UNLOCK buttons must be pressed and held for 3 seconds.
LOCKING FLOOR Informs the operator that the floor locks are being engaged.
FLOOR LOCKED Informs the operator that the floor locks have been successfully engaged.
UNLOCKING FLOOR Informs the operator that the floor locks are being disengaged.
ON WHEELS Informs the operator that the table is on its casters and is mobile.
NEUTRAL POSITION / REPRESS
BUTTON
Informs the operator that the function being moved has reached its intermediate or level position and
that to continue moving the function, the button must be released and then pressed again.
TRENDELENBURG Informs the operator that the table is being placed in Trendelenburg position.
REV. TRENDELNBRG Informs the operator that the table is being placed in reverse trendelenburg position.
HEIGHT UP Informs the operator that the column of the table is being raised.
HEIGHT DOWN Informs the operator that the column of the table is being lowered.
TILTING RIGHT Informs the operator that the table is being tilted to the right.
TILTING LEFT Informs the operator that the table is being tilted to the left.
FLEX Informs the operator that the table top is being moved to flex position.
REFLEX Informs the operator that the table top is being taken out of flex position.
RETURN TO LEVEL Informs the operator that the entire table top is being moved to a level position.
RECHARGE BATTERY / PLUG
CORD IN NOW
Informs the operator that the battery charge has fallen below 1/6 of capacity and that it is imperative that
the power cord be plugged in immediately to allow recharging of the batteries.
BATT LEVEL LOW / RECHARGE
BATTERY
Informs the operator that the battery charge is less than 1/3 of capacity.
BATT LEVEL MED Informs the operator that the battery charge is between 1/3 and 2/3 of capacity.
BATT LEVEL FULL Informs the operator that the battery charge is more than 2/3 of capacity.
CHARGING BATTERY Informs the operator that the table is connected to an electrical outlet and the batteries are being
recharged.
CALIBRATING NEUTRAL POSITION Informs the service technician that the "neutral position" is being calibrated and the data entered into the
main controller board.
SERVICE REQUIRED Informs the operator that the self diagnostic function of the table has detected a table malfunction which
will require service by a qualified service technician.
ERROR CODE Exx Provides information to a qualified service technician as to what type of malfunction exists.
© Schaerer Mayfield USA, Inc. 2004
