Schaerer 7300 - 71075 Foot Rest

SECTION VI
PARTS LIST
Page 6-60
71075 Foot Rest
Always Specify Model & Serial Number
Item Part No. Description Qty.Item Part No. Description Qty.
71075 Foot Rest Assembly (Includes Items
1 thru 6) ................................................ 1
1 • 528-0079-00 • Cushion Foot Rest (Includes Velcro) . 1
• • 053-0105-26 • • Velcro ............................................... 1
2 • 555-0029-00 • Foot Board ......................................... 1
HA540701
3 • 530-0766-00 • Leg Weldment (Left) .......................... 1
4 • 530-0765-00 • Leg Weldment (Right) ........................ 1
5 • 040-0250-18 • Screw ................................................. 8
6 • 71073 • Siderail Clamp Assembly (Refer to
"71073 Siderail Clamp" Elsewhere) .... 2
1
2
3
4
5
5
6
© Schaerer Mayfield USA, Inc. 2004
