SECTION IV
MAINTENANCE / SERVICE
(12) If broken, remove standoffs (6) from pivot block
(9) by unscrewing them.
B. Installation
(1) If removed, install standoffs (6, Figure 4-62) on
pivot block (9).
(2) Install four cable tie standoff assemblies (8) on
distribution board (1) and secure with four
screws (7).
(3) Install distribution board (1) on four standoffs
(6). Push down on corners of distribution board
until locking tabs of standoffs pop back out-
ward, locking distribution board in place.
(4) Connect one wire harness (5) to rear terminals
of distribution board (1).
(5) Connect seven wire harnesses (4) to middle
terminals of distribution board (1).
(6) Connect four wire harnesses (3) to front termi-
nals of distribution board (1).
(7) Connect one wire (2) to terminal of distribution
board (1).
(8) Secure wire and wire harnesses to cable tie
standoff assemblies (8) with cable ties.
(9) Install two cover gaskets (5, Figure 4-61) and
bridge cover (7) on R.H. and L.H. side
weldments (4); then bend lip of cover gaskets
back and install four screws (6).
(10) Install back section table top (3) on R.H. and
L.H. side weldments (4) and secure with four
screws (2).
(11) Install four plugs (1) on back section table
top (3).
Page 4-59Printed in U.S.A.
4.35 RFI Filter Removal / Installation
A. Removal
DANGER
Table is very heavy. Use an assistant
to lay table onto its side. Failure to do
so could result in serious personal injury.
(1) Lay table onto its left side.
DANGER
Make sure power cord is unplugged
before working on table. Failure to do
so could result in electrical shock which could
cause serious personal injury or death.
(2) Unplug power cord from table.
(3) Remove five screws (1, Figure 4-63) and battery
cover (2) from base weldment (3).
(4) Loosen two locknuts (4) and remove caster (5)
from caster fork (6).
(5) Remove jam nut (7).
(6) Remove setscrew (8) and partially pull floor lock
cylinder (9) out of base weldment (3).
(7) Remove two screws (10) and partially remove
bracket assembly (11) from base weldment (3).
(8) Tag and disconnect two wires (1, Figure 4-64)
and three wire groups (2) from terminals of RFI
filter (3).
(9) Remove two locknuts (4) and RFI filter (3) from
bracket assembly (5).
B. Installation
(1) Install RFI filter (3, Figure 4-64) on bracket
assembly (5) and secure with two locknuts (4).
(2) Connect three wire groups (2) and two wires (1)
to terminals of RFI filter (3).
(3) Install bracket assembly (11, Figure 4-63) on
base weldment (3) and secure with two screws
(10).
© Schaerer Mayfield USA, Inc. 2004
