Schaerer 7300 - 71130 I.A. Board (36-Inch)

SECTION VI
PARTS LIST
Printed in U.S.A.
Page 6-89
71130 I.A. Board (36-inch)
Always Specify Model & Serial Number
Item Part No. Description Qty.Item Part No. Description Qty.
71130 I.A. Board (36-inch)
(Includes Items 1 thru 8) ...................... 1
1 • 10360 • Safety Strap ....................................... 1
2 • 528-0126-00 • Cushion (Includes Items 3 thru 6) ...... 1
3 • • 053-0131-25 • • Velcro Hook ..................................... 2
4 • • 053-0105-13 • • Velcro Loop ...................................... 2
5 • • 561-0244-00 • • Cleaning Instructions Label ............... 1
6 • • 061-0041-00 • • Law Label ......................................... 1
7 • 529-0780-00 • Carbon Fiber Board Assembly
(Includes Item 8) ................................ 1
8 • • 561-0343-00 • • Serial Number / X-ray Label .............. 1
9 • • 561-0203-00 • • Weight Rating Label ........................... 2
CA820600
3
4
5
2
3
7
6
8
1
4
9
© Schaerer Mayfield USA, Inc. 2004
