Schaerer 7300 - Page 209

SECTION VI
PARTS LIST
Page 6-93
Always Specify Model & Serial Number
Item Part No. Description Qty.Item Part No. Description Qty.
73004 55-inch Image Amplification Extention
(Includes Items 1 thru 14) .................... 1
1 • 053-0050-00 • Snap Bushing ..................................... 6
2 • 040-0437-05 • Screw ................................................. 6
3 • 529-0718-00 • Carbon Fiber Board ........................... 1
4 • 520-0055-07 • Handle ................................................. 2
5 • 551-0752-00 • Left Mounting Block ........................... 1
6 • 045-0001-115 • Washer ............................................... 6
CA820500
73004 55-inch Image Amplification
Extention with Cushion
7 • 041-0437-03 • Lock Nut ............................................. 6
8 • 551-0742-00 • Right Mounting Block ......................... 1
9 • 561-0385-00 • Accessory Handle Label .................... 2
10 • 528-0148-00 • Cushion (Includes Items 11 thru 14) ... 1
11 • • 561-0244-00 • • Cleaning Instructions Label .............. 1
12 • • 061-0041-00 • • Law Label .......................................... 1
13 • • 053-0105-35 • • Velcro Loop ....................................... 2
14 • • 053-0131-33 • • Velcro Hook ...................................... 2
© Schaerer Mayfield USA, Inc. 2004
