2.2 Abbreviations used
Abbreviation
Meaning
AC
Alternating Current
IL
Instruction List
BGIA (IFA)
Institute for Industrial Safety at the DGUV (German
Statutory Accident Prevention Association)
CLK
Here: SSI systems clock
CPU
Central Processing Unit
DC
Direct Current
DIN
Deutsches Institut für Normung
DO
Digital Output
ECFS
EtherCAT Fail Safe;
EtherCAT FSoE (Fail Safe over EtherCAT)
EMU
EDM
Emergency Monitoring Unit
(External Device Monitoring)
EMC
Electro Magnetic Compatibility
EN
European Norm
Encoder
Position measuring system (position, angle)
Encoder interfaces
Electrical connection feature for an individual encoder
(rotary encoder or proximity switch)
FW
Firmware; software embedded in electronic devices
(embedded software)
G.P.
UL rating; also known as "general use"
HISIDE
Output that switches to positive with 24 VDC nominal level
IFA (BGIA)
Institute for Industrial Safety at the DGUV (German
Statutory Accident Prevention Association)
I00..I13
Digital Input
IQIx
Configurable safe digital I/Os; version: Input
IQQx
Configurable safe digital I/Os; version: Output
IPxx
Degree of protection for housing
Ix.y
(1)
Digital Input
ISO
International Organisation for Standardisation
LED
Light Emitting Diode
LOSIDE
Output that switches to reference potential
n.a.
not applicable
OLC
Operational Limit Control
