schmersal PSC1-C-10 Series User Manual

Installation manual
HB-37350-810-01-50F-EN PSC1-C-10 Installation manual V2.1.docx Page 87 of 189
Version: 50F
4.3.5 Digital outputs I/O (IQQx)
The expansion modules PSC1-E-31-… and PSC1-E-33-… have configurable safe digital I/O
(see section 3.6 Module overview). Configured as an output, this connection acts as a safe
digital pp switching output (IQQx).
4.3.5.1 Classification of the I/O (IQQx) on usage as an output
Classification
Achievable PL
according to EN
ISO13849-1
Remark
Static single-channel
2)
PL c
- Fault detection and fault reaction as
per sec. 2
Static dual-channel
2)
PL d
Same group
1)
:
- Operation delayed at PLC level
- Fault assumption short-circuit on both
outputs
Different group
1)
:
- No further requirement necessary
PL e
Different group
1)
Dynamic single-channel
2)
PL e
No further requirement necessary
Dynamic dual-channel
2)
Note:
1)
Group 1: IQQ00 … IQQ05
Group 2: IQQ06 … IQQ09
2)
Static: No pulse test on the output
Dynamic: Pulse test on the output with t
Test
≤ 500 µs
