Installation manual
HB-37350-810-01-50F-EN PSC1-C-10 Installation manual V2.1.docx Page 29 of 189
Version: 50F
3.7.2 Central expansion modules
3.7.2.1 PSC1-E-31 and PSC1-E-33
Type designation
Device features
Version of the module with following
peripherals:
12 digital inputs
10/6 digital I/O
2 pulse outputs
2 signal outputs
0/4 relay outputs (1-channel) (PSC1-E-
31/33)
12 status LEDs for inputs
2 status LEDs for signal outputs
0/4 status LEDs for relay outputs
(PSC1-E-31/33)
10/6 status LEDs for I/O (PSC1-E-31/33)
