Installation manual
HB-37350-810-01-50F-EN PSC1-C-10 Installation manual V2.1.docx Page 37 of 189
Version: 50F
3.7.4.1 Tech. characteristic data: Optional universal communication interface
Safety-related characteristic data
PL according to EN ISO 13849
n.a.
PFH / architecture
n.a.
SIL according to EN 61508
n.a.
Proof test interval
n.a.
General data
Decentral communication interfaces
(SDDC in preparation)
2x RJ 45*
Fieldbus interfaces
-FB1
2x RJ 45**
-FB2
1x Sub-D***
Memory Card (safety program)
1x microSD (front side)
SD bus (on request)
Connector (with screw terminals)
Status LEDs
4
Fieldbus address rotary switches
-FB2
2
Electrical data
Power consumption (SD bus)
3.6 W
Environmental data
Temperature
0° … +50° C operating temp.;
-25C° … +70C° storage, transport
Degree of protection
IP 20
Climatic class
3k3 according to DIN 60 721
EMC
Corresponding to EN 55011 and EN 61000-6-2
Mechanical data
Size (HxDxW [mm])
100x115x22.5
Attachment
Can be snapped to DIN rail
Number of T-bus
Included in the items supplied
Min. connection cross-section / AWG
0.2 mm² / 24
Max. connection cross-section / AWG
2.5 mm² / 12
Options
* Optionally for SDDC or SMMC (on request)
** Available fieldbuses EtherNet/IP, PROFINET and EtherCAT
*** Available fieldbuses PROFIBUS, CANopen
