schmersal PSC1-C-10 Series User Manual

Installation manual
HB-37350-810-01-50F-EN PSC1-C-10 Installation manual V2.1.docx Page 38 of 189
Version: 50F
3.7.4.2 Possible combinations
FBx module is built into the following devices and not available separately.
Versions
-FB1
-FB2
SDDC
(1)
SMMC
(2)
Module type
PSC1-C-10
x
x
x
x
PSC1-C-10-SDM1
x
x
x
x
PSC1-C-10-SDM2
x
x
x
x
PSC1-E-31
PSC1-E-33
PSC1-E-37
x
Options:
(1)
(in preparation) / always with option -FB1/2 or integrated in the module PSC1-E-37
(2)
(on request) / always with option –FB1/2
3.7.4.3 Using the memory card
Any industrial microSD card between 2 MB and 16 GB may be used with FAT16 or
FAT32 file system.
The safety-related application program with its parameters, also called "configuration", and the
"network configuration" is created with the SafePLC2 programming system.
The two configurations must be renamed before they are copied to the memory card in a
folder "bin", which must be created in the root directory.
Project configuration
Sampleproject.cfg2
config.cfd
Network configuration
Sampleproject.cfdNetwork
network.cfd
After the copying process has been completed, the card can be inserted into the slot at the
front.
Now switch the supply voltage off and on again.
After booting, the system generates the alarm "A01212", an indication that there are different
configurations in the system and on the card. If the configurations are the same, the known
boot sequence runs.
Now press the function button on the front twice within 3 seconds.
The system now switches to stop status. A "5" appears in the 7-segment display.
The entire configuration including the network configuration has now been transferred from the
card to the security control system.
When using an FB1 or FB2 option, LED 2 flashes rapidly.
The system is started automatically with this configuration.
