Installation manual
HB-37350-810-01-50F-EN PSC1-C-10 Installation manual V2.1.docx Page 33 of 189
Version: 50F
3.7.3 Decentralised expansion modules (in preparation)
3.7.3.1 PSC1-E-37
Type designation
Device features
Version of the module with following
peripherals:
14 digital inputs
2 pulse outputs
2 relay outputs (1-channel)
2/4 pn or pp switching outputs
2 signal outputs
1 7-segment display
1 status LED
2 status LEDs for signal outputs
14 status LEDs for inputs
2 status LEDs for relay outputs
4 status LEDs for outputs
Properties of the module:
 14 safe inputs, OSSD support
 Cross-circuit monitoring
 Contact multiplication or contact rating increase by means of external contactors in
conjunction with integrated monitoring possible
 Comprehensive diagnostic functions integrated in the firmware
 Mounting on DIN rail
