Installation manual
HB-37350-810-01-50F-EN PSC1-C-10 Installation manual V2.1.docx Page 31 of 189
Version: 50F
3.7.2.2 Tech. characteristic data: PSC1-E-31 and PSC1-E-33
Safety-related characteristic data
PL according to EN ISO 13849
PL e
PFH / architecture
9,2 * 10
-9
/ KAT 4
(1)
+ on PSC1-E-33
1-channel per relay 2 * 10
-8
(KAT 1)
2-channel per relay 1 * 10
-9
(KAT 4)
SIL according to EN 61508
SIL 3
Proof test interval
20 years = max. service life
General data
Max. number of expansion modules
-
Interface for expansion modules
T-bus connector, can be plugged into DIN rail
Number of safe digital inputs
12 (OSSD support)
Number of safe digital outputs
-
Number of safe digital I/O
PSC1-E-31
10
PSC1-E-33
6
Number of relay outputs (1-channel)
-
PSC1-E-31
-
PSC1-E-33
4
Number of safe analogue inputs
-
Number of signal outputs
2
Number of pulse outputs
2
Type of connection
Removable screw terminals
Axis monitoring
-
Encoder interfaces (D-Sub / screw terminals)
-
Encoder technology (See table Encoder specifications)
-
Electrical data
Supply voltage (tolerance)
24 VDC; 2A (-15%, +20%)
Fuse
A1.1
30 VDC/ 10 A
Max. power consumption (logic)
7.1 W
Rated data digital inputs
24 VDC / 20 mA, type 1 according to EN61131-
2
Rated data digital outputs
Signal outputs
24 VDC; 250mA
Pulse outputs
24 VDC; 250mA
Digital I/O 00 – 04
05 – 09
24 VDC; 0.5A
24 VDC; 2A ***
Rated data relay
-
NO DC13
AC15
24 VDC; 2A
230 VAC; 2A
NC DC13
(readback contact)
24 VDC; 2 A
Rated data analogue inputs
-
Electrical data (only for UL)
Rated data digital outputs
Auxiliary outputs
24 VDC; 250mA (G.P.)
Digital I/O 00 – 04
24 VDC; 0.5A (G.P.)
05 – 09
Temperature rating
30°C
24 VDC; 2A (G.P.)
Temperature rating
50°C
24 VDC; 1.8A
(G.P.)
Max. cumulative current
10A
Rated data relay
Normally open contact
24 VDC; 2A (Pilot Duty)
120 VAC; 2A (Pilot Duty)
Normally closed
(readback contact)
24 VDC; 2A (Pilot Duty)
Environmental data
Temperature
0°C … +50°C operation
-25C° … +70C° storage, transport
Degree of protection
IP 20
Climatic class
3k3 according to DIN 60 721-3
Minimum, maximum relative
humidity (no condensation)
5% - 85%
EMC
EN 61000-6-2, EN 61000-6-4, EN 61000-6-7,
EN 61800-3, EN 61326-3, EN 62061
Use of operating equipment
2000m
Overvoltage category
III
Level of contamination
2
