3.9 Marking
The type plate is attached to the left side wall of the module and contains the following
information:
3.9.1 Type plate
 Type designation
 Part number/item number
 Serial number
 Hardware release identifier
 Software release identifier
 Safety category
 Properties of the power supply
 Properties of the inputs
 Properties of the outputs
 Date of manufacture (CW/year)
 UL relevant data
 Strings between "*" and "#" represent bar codes
3C9/2017
123456
103008445Product No.:
Serial No.:
HW-Release:
FW-Release:
Date:
Type:
PSC1-C-10-SDM1-FB1
*02-01-00-06#
*07A-07C-04A-04A-03A#
*103008441-123456#
Power:
INPUT:
Q0...Q3 (Digital):
Y0...Y1 (Auxiliary): 24 VDC / 0,25 A
NORM:
24 VDC / -15%...+20% / 0...50°C
EN ISO 13849-1Cat. 4 / PL e:
SIL 3: IEC 61508 / IEC 62061
A1.1 / .2 / .3:
2 A / 9 A / 0,25 A
24 VDC
OUTPUT:
I00...I13 (Digital):
A1.1 - A1.3:
Q4...Q5 (Relay): 240 VAC / 24 VDC / 2 A
24 VDC / 2 A
K.A. Schmersal GmbH & Co. KG, DE-42279 Wuppertal
Möddinghofe 30 www.schmersal.com Read manual before installation!
Main supply: 24 V⎓, SELV/PELV;
Power consumption: 24 V⎓ / 2 A; OUT PUT (general use):
- Digital: Q0-Q3 | 24 V⎓ / 2 A, max. total current: 8 A;
- Auxiliary: 24 V⎓ / 250 mA;
- Relay NO (pilot duty): 24 V⎓ / 2 A; 120 V∿ / 2 A
05-00-00-05
11-11-07
LISTED
E304506
IND.CONT.EQ.
LISTED
E304506
IND.CONT.EQ.
MAC: 14-C3-C2-01-XX-XX
01-05-02FW-Rel.COM1:
01-03-01FW-Rel.COM2:
Type plate PSC1-C-10-SDM1
