3.7.5 Encoder specifications
Encoder
type
Connection
Diagnostics
Value
SIN/COS; TTL
X1; X2
Max. frequency
200 kHz
Amplitude SIN/COS
1 Vss +/- 0,3 V
Type of connection
Sub-D 9-pin
SSI absolute
X1; X2
Clock frequency
Master mode 150 kHz / slave mode max. 250 kHz
Max. frame length / data length
32 / 28 bits
Pos. user data
Adjustable
Type of connection
Sub-D 9-pin
Proximity switch / HTL
I04 – I07
Max. frequency
10 kHz (Proxy 2 only 4 kHz, see 5.12.2.5)
Type of connection
Removable screw terminal
3.8 Derating outputs
Maximum current carrying capacity based on temperature.
This "derating" must be taken into account for all 2A outputs (IO board and REL board)!
At an ambient temperature of up to 30°C the 2A outputs may be fully loaded.
From an ambient temperature of 30°C to a maximum of 50°C, the 2A outputs may only be
loaded up to a maximum of 1.8A and the total current may not exceed 10A.
