Installation manual
HB-37350-810-01-50F-EN PSC1-C-10 Installation manual V2.1.docx Page 183 of 189
Version: 50F
General parameters correctly configured
Parameters sensor 1 correct
Parameters sensor 2 correct
12.3.9 Performance of system tests / FIT test (Fault Injection Test)
For the FIT test the manufacturer must prepare a complete list of functions to be tested. This
list includes the safety functions defined as well as fault tests for checking the correct
response of the SRP/CS to these faults.
Example test list:
No.
Setup
Test
Result
1 Test SLS for max. speed setting up mode
Activate setting up mode
Movement with max.
permitted speed
 Diagnostics on the actual speed
versus SLS limit
 Tamper with the setting up speed so
it is above permitted limited speed
2 Test SSX for stop category 2
Movement with max.
speed
Actuate EMERGENCY
STOP
 Diagnostics on the SSX ramp
against the actual deceleration ramp
 Set an inadmissibly slow
deceleration
 Move the axis after reaching
standstill by tampering with the drive
3 Test on the 2-channel door monitoring
Select setting up mode
operating mode
 Diagnostics on the inactive
monitoring with door closed (by
means of diagnostic function FUP)
 Diagnostics on the active monitoring
with door open (by means of
diagnostic function FUP)
 Disconnect a channel and open the
door
 Generate cross-circuit between the
two inputs
