schmersal PSC1-C-10 Series User Manual

Installation manual
HB-37350-810-01-50F-EN PSC1-C-10 Installation manual V2.1.docx Page 181 of 189
Version: 50F
12.3.8.2 Validating FUP against IL and parameters using validation report
The programming in the FUP is to be compared with the IL listing in the validation report.
Example IL listing in the validation report
Validation report
PLC program
Index
Command
Operand
Validated
1
NO1
SLI_EN.1
2
NO1
SLI_EN.2
3
NO1
SLI_EN.3
4
NO1
SCA_EN.1
5
NO1
SCA_EN.2
6
NO1
SCA_EN.3
7
NO1
SLS_EN.2
8
NO1
SCA_EN.4
9
NO1
SLS_EN.3
10
NO1
SLS_EN.4
11
NO1
SLI_EN.5
12
SQH
13
LD
I0.00
14
ST
MX.2
15
SQC
16
SQH
17
LD
I0.02
18
AND
I0.03
19
ST
MX.3
20
SQC
A stepwise check is recommended. The check is all the more efficient the more the
programming in the FUP has been structured.
