Installation manual
HB-37350-810-01-50F-EN PSC1-C-10 Installation manual V2.1.docx Page 19 of 189
Version: 50F
3.7.1.2 Tech. characteristic data PSC1-C-10 (-FBx
(1)
/MC)
Safety-related characteristic data
PL according to EN ISO 13849
max. PL e
PFH / architecture
12.6 * 10
-9
/ KAT 4
SIL according to EN 61508
SIL 3
Proof test interval
20 years = max. service life
General data
Max. number of expansion modules
2
Interface for expansion modules
T-bus connector, can be plugged into DIN rail
Number of safe digital inputs
14 (OSSD support)
Number of safe digital outputs
pn switching** or
2
pp switching **
4
Number of safe digital I/O
-
Number of relay outputs (1-channel)
2
Number of safe analogue inputs
-
Number of signal outputs
2
Number of pulse outputs
2
Type of connection
Removable screw terminals
Axis monitoring
-
Encoder interfaces (D-Sub / screw terminal)
-
Encoder technology (See table Encoder specifications)
-
Electrical data
Supply voltage (tolerance)
24 VDC; 2A (-15%, +20%)
Fuse
A1.1
min. 30 VDC; max. 3,15A
A1.2
min. 30 VDC; max. 10A
Max. power consumption (logic)
PSC1-C-10
3.1W
PSC1-C-10 (-FBx
(1)
)
6.5W
Rated data digital inputs
24 VDC / 20 mA, type 1 according to
EN61131-2
Rated data digital outputs
pn switching
24 VDC; 2A ***
pp switching
24 VDC; 2A ***
Signal outputs
24 VDC; 250mA
Pulse outputs
24 VDC; 250mA
Rated data relay
NO DC13
AC15
24 VDC; 2A
230 VAC; 2A
Rated data analogue inputs
-
Electrical data (only for UL)
Rated data digital outputs
pn switching
Temperature rating
30°C
24 VDC; 2A (G.P.)
Temperature rating
50°C
24 VDC; 1.8A (G.P.)
pp switching
Temperature rating
30°C
24 VDC; 2A (G.P.)
Temperature rating
50°C
24 VDC; 1.8A (G.P.)
Max. cumulative current (pn
or pp)
8A
Auxiliary outputs
24 VDC; 250mA (G.P.)
Rated data relay
Normally open contact
24 VDC; 2A (Pilot Duty)
120 VAC; 2A (Pilot Duty)
