schmersal PSC1-C-10 Series User Manual

Installation manual
HB-37350-810-01-50F-EN PSC1-C-10 Installation manual V2.1.docx Page 20 of 189
Version: 50F
Environmental data
Temperature
0°C … +50°C operation
-25C° … +70C° storage, transport
Degree of protection
IP 20
Climatic class
3k3 according to DIN 60 721-3
Minimum, maximum relative
humidity (no condensation)
5% - 85%
EMC
EN 61000-6-2, EN 61000-6-4, EN 61000-6-7,
EN 61800-3, EN 61326-3, EN 62061
Use of operating equipment
2000m
Overvoltage category
III
Level of contamination
2
Mechanical data
Size (HxDxW [mm])
PSC1-C-10 = 100x115x45
PSC1-C-10 (-FBx
(1)
/-MC) = 100x115x67,5
Weight
PSC1-C-10 = 300 g
PSC1-C-10 (-FBx
(1)
/-MC) = 400 g
Attachment
Can be snapped to DIN rail
Number of T-bus connector
Included in the items supplied
PSC1-C-10
2
PSC1-C-10 (-FBx
(1)
/MC)
3
Min. connection cross-section / AWG
0.2 mm² / 24
Max. connection cross-section / AWG
2.5 mm² / 12
Options:
**
pn/pp can be configured via SafePLC2
***
Derating, see section "Derating of outputs"
(1)
For version see: "Optional universal communication interface"
(2)
on request
(3)
in preparation
