5.12.2.2 Incremental encoder
Physical layer: RS-422 compatible
Measured signal A/B: Track with 90 degree phase difference
Maximum input pulse frequency: 200 kHz
(1)
or 500 kHz
(2)
Options:
(1)
Standard incremental
(2)
HighRes incremental (on request);
Diagnostics:
Diagnostics
Parameter
Fault threshold
Supply voltage monitoring
Fixed values
5 V, 8 V, 10 V, 12 V, 20 V,
24 V
See section 5.9.1
Incremental, HTL (on
request), SIN/COS, SSI
Monitoring differential level
on the input
Fixed value RS 485 level
+/- 20% +/-2% (measuring
tolerance)
Monitoring of the count
signal separately for each
track A/B
Fixed value
DP > 4 increments
5.12.2.3 SineCosine encoder – standard mode
Physical layer: +/- 0.5 Vpp (without voltage offset)
Measured signal A/B: Track with 90 degree phase difference
Maximum input pulse frequency: 200 kHz
1)
or 500 kHz
2)
Options:
(1)
like Standard incremental
(2)
HighRes Sin/Cos (on request);
Diagnostics:
Diagnostics
Parameter
Fault threshold
Supply voltage monitoring
Fixed values
5 V, 8 V, 10 V, 12 V, 20 V,
24 V
See section 5.9.1
Incremental, HTL (on
request), SIN/COS, SSI
SIN²+COS² amplitude
monitoring
Fixed value 1V
pp
65% or 1 V
pp
+/- 2.5%
(measuring tolerance)
Monitoring of phase A/B
Fixed value 90°
+/- 30° +/-5° measuring
tolerance)
5.12.2.4 proximity switches
Signal level: 24 V/0 V
Max. count pulse frequency: 10 kHz
Min. count pulse frequency: 4 Hz
De-bounced switching logic
Diagnostics:
Diagnostics
Parameter
Fault threshold
Monitoring of supply voltage
not possible
-
-
