Installation manual
HB-37350-810-01-50F-EN PSC1-C-10 Installation manual V2.1.docx Page 139 of 189
Version: 50F
7 Commissioning
7.1 Procedure
Commissioning is only allowed to be undertaken by qualified personnel!
Please follow the safety instructions during commissioning!
7.2 Sequences for switching on
Each time after restarting the module, if there are no errors, the following phases are run
through and displayed on the seven-segment display on the front:
7-segment
display
Mode
Description
"1"
STARTUP
Synchronisation between both processor systems and
checking the configuration/firmware data
"2"
SENDCONFIG
Distribution of the configuration/firmware data
and further checking of these data. Subsequent
range calculation for the configuration data.
"3"
STARTUP BUS
If present, initialisation of a bus system
"4"
RUN
Normal operation of the system. All outputs are switched
based on the actual state of the logic.
"5"
STOP
Parameter data and program data can be loaded externally
in the stop mode.
"A"
ALARM
Alarm can be reset via digital input or reset button on the
front.
"E"
ECS alarm
ICS alarm
ACS alarm
ECS alarm can be reset via digital inputs or reset button on
the front.
"F"
Fault
Faults can only be reset via module ON/OFF.
"."
F-Bus Status
Slave F-Bus (PROFIsafe/FSoE):
Off: F bus not used
Slow flashing: F bus configured, no connection to the
master
Fast flashing:
Connection to the master, F bus activation pending
On: F bus connected
